The Q600, Q602 and Q606 are 6-button industrial wireless remote controls designed for electric hoists, single-hook cranes, workshop cranes and hoist-type overhead crane systems.
Q600 is suitable for single-speed crane control, Q602 supports a mixed-speed configuration with 2 double-speed buttons and 4 single-speed buttons, while Q606 is designed for full double-speed operation. This series is ideal for lifting equipment that requires stable wireless control, easy receiver matching and reliable daily operation.
Built with a Semtech LLCC68 low-power wireless communication chip, the Q Series supports stable signal transmission, hardware frequency hopping and carrier sensing for stronger anti-interference performance. The ergonomic transmitter and silicone anti-drop cover also provide a comfortable grip and better protection in industrial working environments.
| Item | Q600 | Q602 | Q606 |
|---|---|---|---|
| Type | Q600 | Q602 | Q606 |
| Transmitter Function | 6 single-speed buttons | 2 double-speed buttons + 4 single-speed buttons | 6 double-speed buttons |
| Recommended Application | Single-speed electric hoist, single-hook crane, workshop lifting equipment | Mixed-speed hoist, workshop crane, lifting equipment with auxiliary functions | Double-speed electric hoist, crane system requiring flexible speed control |
| Item | Q600 / Q602 / Q606 |
|---|---|
| Transmitter Dimensions | 19 × 7.2 × 3.9 cm |
| Transmitter Weight | Approx. 300 g |
| Transmitter Antenna | Built-in antenna |
| Receiver Antenna | Built-in antenna / optional external antenna |
| Start Method | Press the start button |
| Emergency Stop | Mushroom emergency stop button, designed according to EN 13849-1 standard |
| Housing Material | Reinforced nylon plastic |
| Protection Grade | IP65 |
| Control Distance | ≥250 m; custom distance available |
| Frequency | 433 / 480 MHz |
| Operating Temperature | -35°C to +75°C |
| Button Life | ≥2,000,000 operations |
| Power Supply | 2 × AA 1.5V batteries; rechargeable version available as an option |
| Continuous Working Time | Up to 600 hours at room temperature |
| Auto Shutdown | No shutdown by default; 15 min / 30 min auto shutdown can be set by software |
| Button Text | Arrow / English / Chinese / custom text |
| Receiver Output | Relay output, 5A @ 250V |
| Receiver Voltage | DC 12–48V, AC 28–465V |
JYRDI Q Series is available with TI CC1125 or LLCC68 radio platforms. Both are designed for reliable industrial crane control, while each platform offers different communication characteristics for different operating environments.
TI CC1125
Stable industrial communication with strong interference resistance, suitable for demanding factory environments with cranes, motors and variable-frequency drives.
LLCC68
Flexible frequency management for multi-remote environments, larger workshops and applications requiring extended operating range.
Not sure which version to choose?
Tell us your crane type, operating distance and number of remote systems, and we will recommend the suitable configuration.
Not sure whether this model fits your equipment? Tell us your application requirements, and JIAYI will help you choose the right industrial remote control solution.
24/7 Response
Fast support for model selection, quotation, customization, and technical questions.
Factory Direct Supply
OEM / ODM, private label, receiver matching, button layout customization, and technical modification are available.
Technical Support
We help confirm receiver voltage, control functions, wiring, pairing methods, and replacement options.
